Functions |
|
---|---|
Print speed |
105 m²/hr - Max Speed (1-pass); 31 m²/hr - High Speed (4-pass); 21 m²/hr - Production Fast (6-pass); 17 m²/hr - Production Quality, Textiles and Backlits (8-pass); 16 m²/hr - High Saturation (12-pass); 12 m²/hr - High Saturation Backlits and Textiles (14-pass) 1 |
Print cartridge/bottle volume delivered |
1 L |
Ink types |
Water-based HP Latex Inks |
Print Cartridges/Bottle, Number |
8 (black, cyan, light cyan, light magenta, magenta, yellow, HP Latex Optimizer, HP Latex Overcoat) |
Print heads |
8 (2 cyan/black, 2 magenta/yellow, 2 light cyan/light magenta, 1 HP Latex Optimizer, 1 HP Latex Overcoat) |
Print Cartridge/Bottle, Color(s) |
Black, cyan, light cyan, light magenta, magenta, yellow, HP Latex Optimizer, HP Latex Overcoat |
Print quality color (best) |
Up to 1200 x 1200 dpi |
Finished output handling |
Roll feed, take-up reel, wiper roller 2, media saver, automatic horizontal cutter (for vinyl, banner and canvas 3, paper-based media, and film) |
Media sizes standard (metric rolls) |
457 to 1625-mm rolls (580 to 1625-mm rolls with full support) |
Roll external diameter |
250 mm |
Roll maximum input |
1 |
Roll maximum weight |
55 kg |
Recommended media |
HP PVC-free Wallpaper (UL GREENGUARD GOLD Certified 4, FSC® certified 5, meets AgBB criteria 6); HP Photo-realistic Poster Paper; HP Premium Satin Canvas; HP Prime Matte Air GP (REACH compliant 7); HP Premium Removable Gloss Adhesive Vinyl (REACH compliant 7) |
Media thickness (metric) |
Up to 0.5 mm |
Media width, maximum |
1625 mm |
Supported Primary Applications |
Banners; Displays; Exhibition and event graphics; Exterior signage; Indoor posters; Interior decoration; Light boxes - film; Light boxes - paper; Murals; POP/POS; Posters; Textile; Vehicle graphics; Window graphics; Stickers |
Media types |
Banners, self-adhesive vinyls, films, fabrics, papers, wall coverings, canvas, synthetics, mesh, textiles 8 |
Model size |
1626 mm |
Print technology |
HP Latex Printing Technologies |
Print repeatability |
95% of colours ≤ 1.5 dE2000 9 |
Connectivity, standard |
Gigabit Ethernet (1000Base-T) |
Dimensions (W x D x H) |
2583 x 852 x 1402 mm |
Package dimensions (W x D x H) |
2800 x 1130 x 1270 mm |
Weight |
261 kg |
Package weight |
368 kg |
Acoustic power emissions (active, printing) |
7.8 B(A) (operating), 5.5 B(A) (idle), <3.5 B(A) (sleep) |
Acoustic pressure emissions |
60 dB(A) (operating), 38 dB(A) (idle), <20 dB(A) (sleep) |
Operating humidity range |
20 to 80% RH (non-condensing) |
Operating temperature range |
15 to 30ºC |
Operating temperature range |
59 to 86ºF |
Power consumption |
1.5-2.5 kW (5 kW peak) (printing), 95 W (ready), <4.7 W 10 (sleep) (<19 W 11 with DFE), <0.25 W (off) |
Power |
Input voltage (auto ranging) 200-240 V (±10%) two wires and PE; 50/60 Hz (±3 Hz); two power cords; 9 A max printer power cord; 13 A max curing power cord |
Electromagnetic compatibility |
Compliant with Class A requirements, including: USA (FCC rules), Canada (ICES), EU (EMC Directive), Australia and New Zealand (RCM), Japan (VCCI), Korea (KCC), China (CCC) |
Energy star certified |
Yes |
Environmental certification |
ENERGY STAR®, RoHS (WEEE, EU, EAEU, China, Korea, India, Ukraine, Turkey), REACH, EPEAT, OSHA, CE marking compliant, Meets AgBB criteria, French VOC A+, UL GREENGUARD Gold, UL ECOLOGO |
Safety |
IEC 60950-1+A1+A2 compliant; IEC 62368-1 compliant; USA and Canada (CSA listed); EU (LVD, EN 60950-1 and EN 62368-1 compliant); Russia, Belarus, and Kazakhstan (EAC); China (CCC) |
Manufacturer Warranty |
One-year limited hardware warranty |
What's in the box |
HP Latex 700 Printer, printheads, maintenance cartridge, printer stand, take-up reel, media feed accessory, user maintenance kit, edge holders, quick reference guide, documentation software, power cords, air purgers, 2-in spindle adaptor |
